With manufacture orders (MO), you can assemble kits and build finished products from raw materials and/or components. See below for full details.

Creating MOs

Please note: Manufacture orders are only available with an inFlow Manufacturing plan.

Need inFlow Manufacturing for Windows? Download it from here.

How to create a manufacture order

Manufacture orders (formally called work orders) don’t need a bill of materials to be set up first, but it makes things easier if they’re already set up. If you do custom work, you can assemble finished products from a blank manufacture order and add the components to the manufacture order on the go.

inFlow will not complete the manufacture order if you do not have enough components in stock. Right-click on the red exclamation marks (not enough stock icons) and click Reorder stock to quickly generate a reordering for your items.

If you prefer, instead of clicking the Complete Order button, you can also click the Pick tab at the bottom and manually pick the components, and then click the Put Away tab to stock the finished product.

By completing the manufacture order, the system will reduce the stock levels of your components and add stock to your finished product. From there, you can sell the finished product in a sales order. You cannot sell the item in order to deduct components – your manufacture order must be completed first.

How to create a manufacture order directly from a sales order

It’s possible to create a manufacture order directly from the sales order screen only if you don’t have enough stock for that item. If you make your products to order, you should ensure that you have stock of your component items. There are two ways to do this, depending on what you want.

Create one manufacture order for one specific sales order

If you want to keep track of manufacture orders corresponding to specific sales orders, click the Copy button at the top of the sales order and click Create manufacture Order. This creates a single manufacture order containing the items for that sales order only, even if you have to create more of the same item for other sales orders.

Tip: It’s also a good idea to keep the manufacture order number the same as the sales order number (e.g. SO-000111 and WO-000111) for easier lookup.

Using the example above, you would end up with a manufacture order for exactly 1 Bicycle and 1 Finished Computer.

Using the Copy and Create Manufacture Order button will automatically create a new manufacture order with all the items that need to be built for all items that have a Bill of Materials set for the item record.

Create manufacture orders for all sales orders

If the items you’re assembling are also listed in other open sales orders, this method allows you to build them all at once. To do this, right-click the red exclamation mark on your sales order, and then click Reorder Products. This will open up the reorder window, and the items needed to be built in manufacture orders can be created by hitting Reorder. It will create a manufacture order for each item that contains the items you need to build, but the quantities would be higher to account for the other open orders and the reorder point.

Any other finished goods that aren’t in the original sales order are not included.

Using the method above, you would end up with two manufacture orders, one containing the Bicycle item and the other having the Finished Computer, with a quantity of at least 1. If you’ve got other sales orders and reorder points for the two items, they’ll be added to the manufacture order so you can make them all in one go.

In the example, it would create 4 Bicycle and 3 Finished Computers, as it uses the current anticipated qty and the reorder point to determine the amount needed to be reordered.

How to partially complete a manufacture order

If you need to, you can split a manufacture order into two: one to assemble right away and the other to leave for later on if you are only assembling them partially.

Please note that you can only split a manufacture order for one product at a time!

To split a manufacture order:

1. Create your manufacture order and add a finished product to assemble, along with its quantity.
2. Right-click on the finished product line and select Split some into new manufacture order...
3. A window will pop up asking you how many of these items you would like to split into a new manufacture order.

inFlow will then split the manufacture order into two based on the quantity you’ve entered (e.g., if you were going to make 20 of the item and decided to split 7, the manufacture orders will have assembled quantities of 13 and 7, respectively, along with the calculated components).

Manufacture order webinar

Updating MOs

How to swap out a component product

If the product you’re creating already has a bill of materials set up, those component items will be listed below the finished product. You can also change component products by removing them and adding a new component to the list.

1. Right-click on the name of the finished product.
2. Select Add Component Product.
3. Start typing in the name of the product, or click into the drop-down field to select the product.
4. Enter the quantity you’d like to add to the manufacture order, then click OK.
5. Right-click on the original component, then click on Remove item.

How to update quantities of the components on a manufacture order

Simply click on the finished product on the left table (so it’s highlighted in blue), then change its quantity on the right:

You’ll notice that the components did not update correspondingly — all you need to do is click the Recalculate required components button at the bottom of the table. The quantity of the components will update to match based on your Bill of Materials!

MO subassemblies

Subassemblies

Do you make your products out of items you’ve assembled ahead of time? We call those items “subassemblies,” and if you don’t have enough of them in stock to make your final product, there’s no need to create a separate manufacture order to build them first.

Instead, you’ll see those items displayed with their components listed in a manufacture order for the finished product. You can also split a subassembly into its own manufacture order!

If you haven’t set up your bill of materials take a look at this guide to learn more.

Adding subassemblies to your bill of materials

When setting up the bill of materials (BOM) for your finished product, inFlow will calculate your product’s cost based on the cost of its components.

If your subassembly is showing a cost of $0 in the BOM, it means that there is no cost associated with it in its product record. You can manually update the cost yourself or build the subassembly first to have inFlow calculate the cost for you.

inFlow will update the cost of your finished product in the product record only after a manufacture order has been completed.

If you don’t have enough stock of your subassembly

If you don’t have enough of the subassembly available, inFlow will ask you to build this subassembly in the manufacture order for your finished product. You can also choose to split the subassembly into its own manufacture order so that you can build the subassembly separately.

Have inFlow build the subassembly in the same manufacture order:

Instead of just seeing your subassembly listed, you’ll see its components listed, too (as in the image below).

In the example above, Pencil is a subassembly of the Box of Pencils (12 pack), which itself is a subassembly of the finished product, the School Kit.

There aren’t enough Pencils to fulfill the manufacture order, but since it has its own bill of materials, inFlow will list its components (Eraser, Lead, Barrel) as part of the larger manufacture order for the finished product, Box of Pencils (12 pack).

When you click “Complete Order,” inFlow will update the quantities of the items used in your manufacture order. In this case, it would reduce the quantities of Erasers, Lead, Barrel, and Pencil Cases and increase the amount of your finished product, the School Kit. Notice that since the subassemblies are used right away for your finished product their individual quantity on hand stays the same.

*Note: inFlow will not complete your manufacture order if you do not have enough components in stock. Right-click on the red exclamation marks (not enough stock icons) and click Create Purchase Order to quickly generate a purchase order for your items.

Split the subassembly into its own manufacture order:

If you don’t have enough of your subassembly, instead of inFlow building it out in the same manufacture order as the finished product, you can split the subassembly into its own manufacture order and build it there.

Right-click on the subassembly and select Split into new Manufacture Order. inFlow will create a new, separate manufacture order for this subassembly.

When this manufacturing order is marked as complete, the expanded view of components for that subassembly will no longer appear in the parent manufacturing order, as you now have enough of it in stock!

Tip: The Order # will automatically be set to match the parent manufacture order to easily track which manufacture order the subassembly was split from.
